Rayyan Saw-Tooth Greenhouse

Structure: • Posts: Made from galvanized tubes, measuring 80×80 mm with a thickness of 2 mm. • Arches: Made from galvanized pipes, 60 mm in diameter with a thickness of 1.5 mm. • Crop Support: Galvanized tube measuring 40×80 mm with a thickness of 1.5 mm. • Purlins: Longitudinal pipes measuring 32 mm in diameter with a thickness of 1.5 mm, galvanized and connecting the arches to the posts. • Gutter: Made of galvanized iron with a thickness of 2 mm. Doors: • Made of aluminum and consist of two detachable parts for ease of agricultural machinery movement. • The greenhouse can also be equipped with a disinfection chamber. Roof and Side Covering: • The greenhouse is covered with European plastic treated against UV rays, with a thickness of 200 microns. • Fly netting is used to cover the side and front ventilation openings. Electrical Panel: • The greenhouse is equipped with an electrical panel and a thermostat (thermal regulators) to control the top and side ventilation. • Includes a weather monitoring station and a wind speed measurement unit. Top Ventilation: •The greenhouse is equipped with top ventilation openings from the gutter to the peak, controlled automatically. Side Ventilation: • The greenhouse is equipped with side ventilation openings, controlled either manually or automatically.
